Video Format Composite NTSC or PAL HDMI, PC-RGB 1920 x 1080 (60 / 50 Hz), 1680 x 1050 (60 / 75 Hz),ġ600 x 900 (60 / 75 Hz), 1440 x 900 (60 / 75 Hz),ġ280 x 1024 (60 / 75 Hz), 1280 x 720 (60 / 50 Hz),ġ024 x 768 (60 / 75 Hz) (Progressive Scan) Sampling Rate 4:2:2 (Y:B-Y:R-Y), 8-bit, 13.5 MHz (ITU-R BT.601) Input / Output Level and Impedance Composite 1.0 Vp-p, 75 ohms PC-RGB 0.7 Vp-p, 75 ohms (H, V : 5V TTL) Connectors Video Input Composite: BNC type x 12 jacks Output Connectors Composite (for MATRIX OUT): BNC type x 4 jacksĬomposite (for MATRIX OUT Preview): BNC type x 1 jack This example is an illustration of standard definition input expansion for the V-1600HD only. The inputs and formats of the MVS-12 and the V-1600HD are not directly compatible. * Please note that the MVS-12 does not function as a multi-viewer for the V-1600HD.

multiviewer video multiviewer video

By connecting a MIDI cable and using the V-LINK function, the V-1600HD can directly select any video source from the MVS-12. The Matrix Switcher function enables the V-1600HD mixer to access additional SD inputs. Video sources can be distributed to up to four different locations. Using a MIDI connection the PGM/PVM video source is displayed and indicated by a red frame and green frame (tally). The MVS-12 is a perfect companion for the LVS-800 allowing you to preview all monitor outputs. Multi-viewer and Matrix switcher function enables system expansion.

Multiviewer video Pc#

In addition, the MVS-12 can be controlled from a PC via LAN or RS-232C. Aspect ratios, background color and source names can be selected from the MENU.įour display setups can be saved and recalled from the 4 front panel memory buttons. There are four layout patterns to choose from.

multiviewer video

Using the built-in Matrix Switcher function, 12 video sources are assignable to 4 different outputs. * Setup MENU also supports mouse operation. Select video source with a click of the mouse. Rearrange screen structure with simple drag and drop motion. Easily monitor and distribute input sources.
